NL6448BC33-59, NL6448BC33-59D, NEC, 10.4", 640x480, TFT LCD PANEL, Size: 10.4" WXGA TFT NEC, Backlight Type: CCFL,
Model number: NL6448BC33-59
- Screen: 10.4" diagonal screen
- Drive method: Amorphous Si TFT active-matrix
- Display area: 211.2(H) x 158.4(V)mm
- Number of pixels:� 640 x 480
- Display color: 262,144 colors
- Pixel pitch: 0.33(H) x 0.33(V)mm
- Pixel arrangement: RGB vertical stripe
- Luminance: 350cd/m2 typical
- Backlight 2 cold cathode fluorescent lamps
- Backlight inverter None
- Contrast ratio 600:1 typical
- Viewing angle Up 45 , down 55o, right 50o, left/right +/-70o
- Response time 33ms max.
- Input signals Digital RGB(6bits), dot clock, H-sync, V-sync
- Power requirements 3.3V(or 5V)
- Power consumption 5.8W typical
- Operating temperature 0oC to +50oC
- Storage temperature -20oC to +60oC
- Outline dimensions 243(W) x 185.1(H) x 10.75 (D)mm
- Weight Approx. 470g
