LTM150XS-T01, SAMSUNG, LTM150XS-T01 is a color active matrix TFT (Thin Film Transistor) liquid crystal display that uses amorphous silicon TFT switching devices. This model is composed of a TFT LCD panel, a driver circuit and a back-light system. The resolution of 15.0- inch contains 1,024 x 768 pixels and can display up to 262,144 colors. 6 o'clock direction is the optimum viewing angle, Active area 304.128(H) x228.096(V) (15 inch diagonal )
Pixel arrangement RGB vertical stripe
Driver element a-Si TFT active matrix
Pixel pitch 0.297(H) x 0.297(W) mm
Surface treatment Haze 12 , Anti-glare Hard - Coating (3H)
Display Mode Normally white
Display colors 262,144
Number of pixel 1024 x 768
LTM150XS-L01 LJ96-00155A
LTM150XS-L02
LTM150XS-L03
LTM150XS-L04
LTM150XS-L05
LTM150XS-L06
LTM150XS-L07
LTM150XS-L08
LTM150XS-L09
Datasheet download link is below.
http://www.pointosale.co.uk/datasheets/LTM150XS-T01.pdf
